AML治療アルゴリズム

AMLと診断された場合の治療選択、フォローアップについて:
ただし、TSに伴うAMLに対するエベロリムスによる薬物治療に関しては現時点における適応がまだ確立されていないため本アルゴリズムには含めていない。
出典
1: 日本皮膚科学会編. 結節性硬化症の診断基準及び治療ガイドライン.(改変あり)

AMLの典型的画像(CT)

32歳、女性。両側腎に脂肪成分を含む腫瘍を認める。右腎は腫瘍により正常部が正中側に偏移している。
出典
1: 著者提供

AMLの典型的画像(超音波)

18歳、女性。TSの診断。右側腹部痛を認める。
a:右腎上極に内部不均一なエコー輝度を示す類円形の腫瘍を認める。
b:右腎下極側にはやや高エコー域を示す腫瘍部分を認める。
出典
1: 著者提供

CT所見および摘出標本

a:左腎中極に脂肪成分を主体とする腫瘍があり、これに連続して下大静脈内まで腫瘍の進展を認める。
b:左腎およびCT画像と同様の形状を示す下大静脈内腫瘍塞栓。
出典
1: 著者提供

上記症例の腫瘍病理所見

病理組織像:成熟した脂肪細胞を主体に、血管成分も認める。
出典
1: 著者提供

脂肪成分に乏しいAML症例の画像所見

CT、 MRIなど画像所見上、明らかな脂肪成分を認めない。
出典
1: Changing trends in presentation, diagnosis and management of renal angiomyolipoma: comparison of sporadic and tuberous sclerosis complex-associated forms.
著者: Seyam RM, Bissada NK, Kattan SA, Mokhtar AA, Aslam M, Fahmy WE, Mourad WA, Binmahfouz AA, Alzahrani HM, Hanash KA.
雑誌名: Urology. 2008 Nov;72(5):1077-82. doi: 10.1016/j.urology.2008.07.049. Epub 2008 Sep 21.
Abstract/Text: OBJECTIVES: To evaluate the changing management of sporadic renal angiomyolipoma and renal angiomyolipoma associated with the tuberous sclerosis complex (TSC) during the past 16 years.
METHODS: We retrospectively reviewed the charts of 60 patients with angiomyolipoma seen at our institutions.
RESULTS: The median age at presentation was 45 years (range 7-78). The presentation was pain in 30 patients and hematuria in 13; it was incidentally discovered in 17 patients. Of the 60 patients, 43 were females. TSC was present in 14 patients. The median tumor size was 4 cm (range 0.3-40, mean 6.5 +/- 1.1). Of the 60 patients, 31 were followed up expectantly. Surgery or intervention was needed for 29 patients to control hemorrhage or relieve pain or because of the suspicion of malignancy. Of these 29 patients, 12 underwent nephrectomy, 11 partial nephrectomy, and 6 embolization. The patients treated for hemorrhage had a median tumor diameter of 11 cm (range 2-21). Patients were followed up for a mean of 39.3 +/- 5.4 months. The lesions grew an average of 4.7 +/- 3.4 cm for TSC tumors and 0.6 +/- 0.2 cm for sporadic angiomyolipoma tumors. None of the patients developed renal impairment. Patients with TSC presented at a younger age, had larger and bilateral lesions, and were more symptomatic during follow-up. In the past 6 years, a significant trend was seen toward finding tumors in asymptomatic patients and toward the use of conservative or interventional (embolization) treatment.
CONCLUSIONS: Renal angiomyolipoma has a slow growth rate. The preservation of renal function was noted in all our patients. A recent shift was noted toward finding smaller tumors in asymptomatic patients and the use of conservative and interventional treatment.
Urology. 2008 Nov;72(5):1077-82. doi: 10.1016/j.urology.2008.07.049. E...

類上皮型AMLのCT所見

脂肪成分を含まず造影効果の乏しい3 cm大の腫瘤。
出典
1: 著者提供

TSに伴うAML症例のCT所見

a:右腎上極には最大径約6 cmの内部に不均一な低吸収域を伴う充実性腫瘍を認める。
b:中極周囲には脂肪組織を含む小腫瘍も散在している。
出典
1: 著者提供

上記症例の血管造影所見

a:右腎動脈造影(腫瘍部の血管増生、微小動脈瘤を認める)。
b:塞栓直後(血管増生部分が軽減~消失しているのがわかる)。
出典
1: 著者提供

上記症例の塞栓術後のCT所見

塞栓術後6カ月(右腎上極の腫瘍の著明な縮小を認める)。
出典
1: 著者提供

シロリムス投与後の腫瘍径の経時変化

12カ月後でベースラインの平均53.2%までの腫瘍縮小効果が得られている。
出典
1: Sirolimus for angiomyolipoma in tuberous sclerosis complex or lymphangioleiomyomatosis.
著者: Bissler JJ, McCormack FX, Young LR, Elwing JM, Chuck G, Leonard JM, Schmithorst VJ, Laor T, Brody AS, Bean J, Salisbury S, Franz DN.
雑誌名: N Engl J Med. 2008 Jan 10;358(2):140-51. doi: 10.1056/NEJMoa063564.
Abstract/Text: BACKGROUND: Angiomyolipomas in patients with the tuberous sclerosis complex or sporadic lymphangioleiomyomatosis are associated with mutations in tuberous sclerosis genes resulting in constitutive activation of the mammalian target of rapamycin (mTOR). The drug sirolimus suppresses mTOR signaling.
METHODS: We conducted a 24-month, nonrandomized, open-label trial to determine whether sirolimus reduces the angiomyolipoma volume in patients with the tuberous sclerosis complex or sporadic lymphangioleiomyomatosis. Sirolimus was administered for the first 12 months only. Serial magnetic resonance imaging of angiomyolipomas and brain lesions, computed tomography of lung cysts, and pulmonary-function tests were performed.
RESULTS: Of the 25 patients enrolled, 20 completed the 12-month evaluation, and 18 completed the 24-month evaluation. The mean (+/-SD) angiomyolipoma volume at 12 months was 53.2+/-26.6% of the baseline value (P<0.001) and at 24 months was 85.9+/-28.5% of the baseline value (P=0.005). At 24 months, five patients had a persistent reduction in the angiomyolipoma volume of 30% or more. During the period of sirolimus therapy, among patients with lymphangioleiomyomatosis, the mean forced expiratory volume in 1 second (FEV1) increased by 118+/-330 ml (P=0.06), the forced vital capacity (FVC) increased by 390+/-570 ml (P<0.001), and the residual volume decreased by 439+/-493 ml (P=0.02), as compared with baseline values. One year after sirolimus was discontinued, the FEV1 was 62+/-411 ml above the baseline value, the FVC was 346+/-712 ml above the baseline value, and the residual volume was 333+/-570 ml below the baseline value; cerebral lesions were unchanged. Five patients had six serious adverse events while receiving sirolimus, including diarrhea, pyelonephritis, stomatitis, and respiratory infections.
CONCLUSIONS: Angiomyolipomas regressed somewhat during sirolimus therapy but tended to increase in volume after the therapy was stopped. Some patients with lymphangioleiomyomatosis had improvement in spirometric measurements and gas trapping that persisted after treatment. Suppression of mTOR signaling might constitute an ameliorative treatment in patients with the tuberous sclerosis complex or sporadic lymphangioleiomyomatosis. (ClinicalTrials.gov number, NCT00457808.)

2008 Massachusetts Medical Society
N Engl J Med. 2008 Jan 10;358(2):140-51. doi: 10.1056/NEJMoa063564.

シロリムス投与が有効であった症例の治療前後でのMRI所見

有効例のMRI画像
a:Baseline
b:12 Months

AMLの自然破裂例のCT所見

右腎に破裂による血腫の形成を認める。
出典
1: 大庭康司郎, 古賀成彦, 錦戸雅春ほか. 破裂をきたした腎血管筋脂肪腫の検討. 腎移植・血管外科, 2003; 15(1): 28-31.

妊娠中に破裂した腎血管筋脂肪腫のCT所見

a:破裂前
b:破裂時
出典
1: [Rupture of renal angiomyolipoma during pregnancy: a case report].
著者: Komeya M, Matsumoto T, Fujinami K, Senga Y, Asakura T, Goto A.
雑誌名: Hinyokika Kiyo. 2010 May;56(5):261-4.
Abstract/Text: A 39-year-old woman, who was followed because of a 4 cm asymptomatic angiomyolipoma (AML) in the left kidney, presented with an acute onset of lower left back pain in the 38th week of her first pregnancy. An ultrasound revealed an 8 cm mass suggestive of AML rupture and retroperitoneal hemorrhage. An emergency caesarean delivery was performed. A post-delivery computed tomographic scan confirmed the AML rupture and selective embolization was performed. This was a case in which the AML grew rapidly during the pregnancy ; therefore, we discuss the relationship between AML and pregnancy.
Hinyokika Kiyo. 2010 May;56(5):261-4.

TAE後に膿瘍形成した症例のCT所見

左腎内部に不整に造影される膿瘍部分を認める。
出典
1: Embolization of renal angiomyolipomas: short-term and long-term outcomes, complications, and tumor shrinkage.
著者: Lee SY, Hsu HH, Chen YC, Huang CC, Wong YC, Wang LJ, Chuang CK, Yang CW.
雑誌名: Cardiovasc Intervent Radiol. 2009 Nov;32(6):1171-8. doi: 10.1007/s00270-009-9637-0. Epub 2009 Jul 2.
Abstract/Text: This study retrospectively evaluated outcomes, complications, and tumor shrinkage in renal angiomyolipomas after transcatheter arterial embolization (TAE). All renal angiomyolipoma patients who underwent TAE between August 2000 and December 2008 and had short-term (6 months) follow-up images were evaluated. Complications and tumor relapse after TAE were reviewed. The sizes of embolized tumors were measured to calculate size reductions and reduction rates after TAE. Differences in tumor size, size reduction, and reduction rate between different time points (pre-TAE, short-term follow-up, and long-term follow-up) and groups (completely and incompletely embolized) were determined. Eleven renal angiomyolipoma patients who had undergone TAE were included. Seven (63.6%) patients had postembolization syndrome and one had abscess formation following TAE. Two patients had a tumor relapse (18.2%). The mean tumor size was 8.57+/-2.66 cm on pre-TAE images. The mean size reduction was 3.1 cm (33.3%) and 3.8 cm (43.0%) at short-term and long-term follow-up. Tumor sizes differed significantly between pre-TAE and short-term (p=0.004) or long-term images (p=0.022) but not between short-term and long-term images (p=0.059). Results stratified by the completeness of embolization indicate that only the short-term size reduction rate differed significantly (p=0.025), while the long-term reduction rate and short- and long-term follow-up tumor size and size reduction were comparable between the two groups. In conclusion, selective TAE is effective for tumor shrinkage in most renal angiomyolipomas, with acceptable complication and relapse rates. Tumor shrinkage occurring within 6 months after TAE may reflect the long-term effect of TAE.
Cardiovasc Intervent Radiol. 2009 Nov;32(6):1171-8. doi: 10.1007/s0027...

腎血管筋脂肪腫のCT画像

32歳女性。両側の腎臓(白く見える部分)に腫瘍の部分(黄色の矢印で囲まれた部分)が連続してあるのがわかる。
出典
1: 著者提供

典型的なCT画像

a:脂肪成分に富む両側性の巨大な腫瘍。
b:結節性硬化症に合併したやや脂肪成分に乏しい部分が主体の腫瘍。
出典
1: 著者提供

AML診断アルゴリズム

腎腫瘤を認めた場合の腎AMLの鑑別診断アルゴリズム
出典
1: 著者提供

AML治療アルゴリズム

AMLと診断された場合の治療選択、フォローアップについて:
ただし、TSに伴うAMLに対するエベロリムスによる薬物治療に関しては現時点における適応がまだ確立されていないため本アルゴリズムには含めていない。
出典
1: 日本皮膚科学会編. 結節性硬化症の診断基準及び治療ガイドライン.(改変あり)

AMLの典型的画像(CT)

32歳、女性。両側腎に脂肪成分を含む腫瘍を認める。右腎は腫瘍により正常部が正中側に偏移している。
出典
1: 著者提供
